APC SRV 3000VA On-Line Tower Easy UPS, 230V, SRV3KI

• Brand: APC by Schneider Electric
• Model: SRV3KI (Easy UPS SRV 3000VA On-Line)
• Type: On-Line Double Conversion Tower UPS
• Capacity:
  • Power Rating: 3000 VA / 2400 W
• Input:
  • Input Voltage: 230V AC
  • Input Voltage Range: 110 – 300V AC
  • Input Frequency: 40 – 70 Hz (auto-sensing)
  • Input Connection: IEC C20 inlet
  • Input Power Factor: ≥ 0.99 (at full load)
• Output:
  • Output Voltage: 230V (configurable to 220V, 230V, or 240V)
  • Output Voltage Regulation: +/- 1%
  • Output Frequency: 50/60 Hz +/- 1 Hz (sync to mains)
  • Output Waveform: Pure sine wave
  • Output Connections: 8 x IEC C13 outlets, 1 x IEC C19 outlet
  • Efficiency: Up to 90% in online mode
• Battery:
  • Battery Type: Sealed, maintenance-free, lead-acid battery
  • Recharge Time: 4 hours to 90% capacity
  • Battery Voltage: 72V DC
  • Backup Time at Full Load: Approximately 5.9 minutes
  • Backup Time at Half Load: Approximately 13.8 minutes
  • Battery Replacement: Hot-swappable, user-replaceable batteries
• Bypass: Internal automatic static bypass
• Management:
  • LCD Display: Multifunction LCD display with status indicators and control options
  • Communication Ports: USB, RS232 serial, and SmartSlot for network management card
  • Remote Monitoring: Network management card compatible for remote monitoring (optional)
• Protection:
  • Surge Protection: Built-in protection against surges, spikes, and power fluctuations
  • Overload Capacity: Supports 105% – 125% overload for 1 minute before transferring to bypass mode
• Tower Design:
  • Form Factor: Tower design for standalone installation
• Environmental:
  • Operating Temperature: 0°C to 40°C (32°F to 104°F)
  • Operating Humidity: 0 – 95% RH (non-condensing)
