PLASTIC EXIT BUTTON WITH LED

It allows you to exit when when you push it if the door does not open with traditional handles.It is  a button installed in the inside of a room, and is wired to the electric  lock equiped  on the door.

• Material: High-impact ABS plastic
• Color: Standard colors include white, black, and grey (custom colors available upon request)
• Dimensions:
  • Faceplate: 86mm x 86mm (standard size, other sizes available)
  • Button Diameter: 25mm to 30mm
• Weight: Approximately 100 grams

Electrical Specifications:

• Voltage Rating: 12V DC (common for most access control systems)
• Current Rating: 3A at 30V DC (maximum)
• Contact Type: SPDT (Single Pole Double Throw) or DPDT (Double Pole Double Throw), depending on model
• Contact Resistance: ≤ 50 mΩ
• Insulation Resistance: ≥ 100 MΩ at 500V DC

Mechanical Specifications:

• Operation Force: 3-5 N
• Button Travel: 1.5mm to 2.5mm
• Lifespan: Rated for over 500,000 cycles
• Mounting: Surface mount or flush mount options available
• Operating Temperature: -20°C to +55°C
• Humidity: 0% to 95% RH, non-condensing

Features:

• LED Indicator: Red/Green bi-color LED for status indication (optional feature)
• Tamper-resistant Design: Options for tamper-resistant versions
• Compliance: Meets or exceeds standards such as CE, FCC, and RoHS
• Environmental Protection: Some models available with IP65 rating for dust and water resistance

Installation:

• Wiring Terminals: Screw terminals or quick-connect terminals for easy installation
• Included Hardware: Mounting screws and backbox (for surface mount models)
• Compatibility: Compatible with most access control systems and automatic door operators
