Ubiquiti NanoStation M2 is a popular outdoor wireless device designed for long-range point-to-point and point-to-multipoint links. It operates on the 2.4 GHz band, providing a robust and stable wireless connection.

Specifications

• Model: NanoStation M2
• Operating Frequency: 2.4 GHz (2412 – 2462 MHz)

Hardware:

• Processor: Atheros MIPS 24KC, 400 MHz
• Memory: 32 MB SDRAM, 8 MB Flash
• Networking Interface: 1 x 10/100 Ethernet Port
• Power Supply: 24V, 0.5A PoE (Power over Ethernet)
• Max Power Consumption: 8 Watts
• Mounting: Pole mounting kit included

Wireless:

• Standards: IEEE 802.11b/g/n
• Maximum Throughput: 150+ Mbps
• Max Range: 13 km+ (Line of Sight)
• Antenna Gain:
  • 10 dBi Dual-Polarized Antenna
  • 3 dBi external RP-SMA Antennas (optional)
• Polarization: Dual-Linear
• Beamwidth: 55° (H-Pol), 53° (V-Pol)
• Output Power: Up to 28 dBm (depending on country-specific regulations)
• Modulation: OFDM, BPSK, QPSK, 16QAM, 64QAM

Software and Features:

• Operating System: airOS, Ubiquiti’s firmware with advanced wireless performance, bridge/routing modes, and remote configuration.
• AirMax Technology: TDMA protocol to improve performance in Point-to-Multipoint deployments.
• Channel Width: Configurable from 5 MHz, 10 MHz, 20 MHz, and 40 MHz.
• Wireless Security: WEP, WPA, WPA2 encryption.
• QoS: Supports advanced QoS for traffic prioritization.
• Management: Through Web UI, Telnet/SSH, SNMP, and airControl.

Environmental:

• Operating Temperature: -30°C to 75°C (-22°F to 167°F)
• Operating Humidity: 5% to 95% Non-Condensing
• Enclosure: UV-Stabilized Plastic, weatherproof for outdoor installation.
